Tetriminos
The core of the game are these shapes you can rotate and fit together. These shapes are called tetriminoes. Let’s start with the base- the Tetromino class. We need something to represent the actual shape, and rotate between them.
In Tetris each of the pieces, tertiminoes, are referred to as: J, L, I, O, T, S and Z
public enum Tetriminoes
{
I,
O,
T,
J,
L,
S,
Z
}
Shapes
We define the shape in each of the orientations by a pattern of booleans.
Let’s have a look at the T tetrimono, it consists of 4 shapes- one for each orientation:
.1. .1. ... .1.
111 .11 111 11.
... .1. .1. .1.
The O tetrimono is the same in every rotation, and looks like this:
11
11
Therefore, not all tetriminoes have the same dimensions and the same number of shapes. So to represent a single shape as a class:
internal class Shape
{
public bool[][] shapeBit;
public Shape(bool[][] shapebits)
{
shapeBit = shapebits;
}
}
To make things a bit easier, this constructor takes a set of strings to construct the bit pattern:
public Shape(string[] shapedefinition)
{
shapeBit =new bool[shapedefinition.Length][];
int j = 0;
foreach (string s in shapedefinition)
{
shapeBit[j]=new bool[shapedefinition.Length];
int i = 0;
foreach (char c in s)
{
shapeBit[j][i] = (c == '1');
i++;
}
j++;
}
}
Tetrimino class
And the shapes together are representing a tetrimino.
internal class Tetrimino
{
public Shape[] Shapes; // the shape definitions
private int _shapeID; //the current active shape
public Color Color; //each tetrimino has its own color
public Tetriminoes ShapeType; //what shape is it?
public Tetrimino()
{
_shapeID = 0;
}
public Shape CurrentShape
{
get
{
return Shapes[_shapeID];
}
}
public void SetShape(Shape[] shapes, Tetriminoes type, Color color)
{
Shapes = shapes;
ShapeType = type;
Color = color;
}
public void RotateLeft()
{
_shapeID++;
if (_shapeID > Shapes.Length - 1)
{
_shapeID = 0;
}
}
public void RotateRight()
{
_shapeID--;
if (_shapeID < 0)
{
_shapeID = Shapes.Length - 1;
}
}
}
The factory
To produce a bunch of these pieces we’re going to use a factory class. A factory is a pattern that instantiates a new object and sets the right properties for you. Look at the code below to see what I mean:
internal class TetriminoFactory
{
public TetriminoFactory()
{
}
public Tetrimino Generate(Tetriminoes shapetype)
{
Shape[] shapes=new Shape[4];
Color color=Color.White;
switch (shapetype)
{
// I - the long one
case Tetriminoes.I:
{
color = Color.Cyan;
shapes[0] = new Shape(new string[]
{
"0000",
"1111",
"0000",
"0000"
});
shapes[1] = new Shape(new string[]
{
"0010",
"0010",
"0010",
"0010"
});
shapes[2] = new Shape(new string[]
{
"0000",
"0000",
"1111",
"0000"
});
shapes[3] = new Shape(new string[]
{
"0100",
"0100",
"0100",
"0100"
});
break;
}
case Tetriminoes.O:
{
color = Color.Yellow;
shapes = new Shape[1];
shapes[0] = new Shape(new string[]
{
"11",
"11",
});
break;
}
case Tetriminoes.T:
{
color = Color.DeepPink;
shapes[0] = new Shape(new string[]
{
"010",
"111",
"000"
});
shapes[1] = new Shape(new string[]
{
"010",
"011",
"010"
});
shapes[2] = new Shape(new string[]
{
"000",
"111",
"010"
});
shapes[3] = new Shape(new string[]
{
"010",
"110",
"010"
});
break;
}
case Tetriminoes.J:
{
color = Color.Blue;
shapes[0] = new Shape(new string[]
{
"100",
"111",
"000"
});
shapes[1] = new Shape(new string[]
{
"011",
"010",
"010"
});
shapes[2] = new Shape(new string[]
{
"000",
"111",
"001"
});
shapes[3] = new Shape(new string[]
{
"010",
"010",
"110"
});
break;
}
case Tetriminoes.L:
{
color = Color.Orange;
shapes[0] = new Shape(new string[]
{
"001",
"111",
"000"
});
shapes[1] = new Shape(new string[]
{
"010",
"010",
"011"
});
shapes[2] = new Shape(new string[]
{
"000",
"111",
"100"
});
shapes[3] = new Shape(new string[]
{
"110",
"010",
"010"
});
break;
}
case Tetriminoes.S:
{
color = Color.Green;
shapes[0] = new Shape(new string[]
{
"011",
"110",
"000"
});
shapes[1] = new Shape(new string[]
{
"010",
"011",
"001"
});
shapes[2] = new Shape(new string[]
{
"000",
"011",
"110"
});
shapes[3] = new Shape(new string[]
{
"100",
"110",
"010"
});
break;
}
case Tetriminoes.Z:
{
color = Color.Red;
shapes[0] = new Shape(new string[]
{
"110",
"011",
"000"
});
shapes[1] = new Shape(new string[]
{
"001",
"011",
"010"
});
shapes[2] = new Shape(new string[]
{
"000",
"110",
"011"
});
shapes[3] = new Shape(new string[]
{
"010",
"110",
"100"
});
break;
}
}
Tetrimino t = new Tetrimino();
t.SetShape(shapes,shapetype,color);
return t;
}
}
Now, whenever we need a tetrimino, we can ask the factory for a type! Very convenient!
Drawing the tetrimino
Finally we want to draw the tetrimino, so let’s add the Draw method to the tetrimono class:
public void Draw(Matrix world)
{
for (int y = 0; y < CurrentShape.shapeBit.Length; y++)
{
for (int x = 0; x < CurrentShape.shapeBit[y].Length; x++)
{
if (CurrentShape.shapeBit[y][x] == false)
continue;
foreach (ModelMesh m in Assets.Models.CubeObject.Meshes)
{
foreach (ModelMeshPart part in m.MeshParts)
{
part.Effect = GameRoot.BasicEffect;
GameRoot.BasicEffect.World = Matrix.CreateTranslation(0.2f * x, 0.2f * -y, 0) * world ;
GameRoot.BasicEffect.DiffuseColor = Color.ToVector3();
}
m.Draw();
}
}
}
}
Note how we have a translation on top of the world parameter. The first one is the topleft corner of the tetromino piece, determined by the world variable. Next translation is based on the x and y of the shape pattern- keep these two things in mind: our cube has the 0.2 unit dimensions (hence th 0.2f in the formula) and y downwards is negative (which is different in 2D where down usually means an increment!)
Putting it together
Now the Title scene as in chapter 1 can be modified to create a tetrimino and rotate it gently- replacing the single cube:
internal class TitleScreen : IScene
{
// Let's rotate the cube for a nice visual effect.
private float _angle;
private Matrix _world;
private Tetrimino.Tetrimino _tetrimino;
public TitleScreen()
{
TetriminoFactory factory = new TetriminoFactory();
_tetrimino = factory.Generate(Tetriminoes.J);
}
public void Update(GameTime gameTime)
{
// Increase the angle framerate independant:
// 0.75 radians per second, also keep the rotation within the 2 PI bound.
_angle += 0.75f * (float)gameTime.ElapsedGameTime.TotalSeconds;
_angle %= MathHelper.TwoPi;
_world= Matrix.CreateScale(5) * Matrix.CreateRotationY(_angle) * Matrix.CreateTranslation(0, 0, -3f);
}
public void Draw(SpriteBatch spriteBatch, GameTime gameTime)
{
_tetrimino.Draw(_world);
}
}
This should result in the blue J-piece showing:
Continue
Next step: The Grid.
